SCM-1200N2

Coating Machine

The automatic emulsion coating unit features SERIA's proprietary mechanism for uniform emulsion application, a task challenging to achieve with traditional hand coating. It is designed for ease of use, requiring no specialized skills or experience thanks to its user-friendly settings.

Request Information
  • Design Concept
  • Features
  • Images
  • Technical Specifications
The automatic emulsion coating unit features SERIA's proprietary mechanism for uniform emulsion application, a task challenging to achieve with traditional hand coating. It is designed for ease of use, requiring no specialized skills or experience thanks to its user-friendly settings.
  • Bucket pressure left/right control function
  • Carriage AC servo & timing belt driven
  • High operatibility by adopting user fiendly design
  • Numerical control of operating condition (only with parameter model)

scm1200_1



Max. Frame Size W1000 × H1200 mm
Min. Frame Size W300 × H300 mm
Frame Thickness 20t - 40t mm
Coating Squeegee-Side, Print-Side or Both Sides
Coating Speed 0 - 8 m/sec
Trough Descent Speed 16 m/sec
Trough Pressure Control Automatic Trough Pressure + Springs
Frame Holders Air Clamp
Power Supply 3φ AC200V 50/60Hz 0.3 kW
Compressed Air 30 liters/min (0.5 MPa)
Dimensions W1790 × H1815 × D480 mm
Weight 300 kg
